空氣室空氣彈簧阻尼的性能
時間: 2019-03-11 17:01 瀏覽次數：
空氣室空氣彈簧系統由空氣彈簧本體，節流孔以及附加空氣室組成，其阻尼作用通過節流孔實現。空氣彈簧在受到外界載荷作用產生形變時，空氣彈簧本體與附加空氣室之間形成壓力差。當空氣彈簧在靜態形變時，即列車靜止或低速行駛狀態下，壓力差較小，節流孔不產生較大的阻尼力。而在列車高速運行中，空氣彈簧振動加劇，空氣彈簧本體與附加空氣室壓力差增大，節流孔產生明顯的阻尼作用，吸收振動能量，達到衰減振動的作用。
The air spring system of additional air chamber is composed of air spring body, throttle hole and additional air chamber.When the air spring is deformed by external load, the pressure difference between the air spring body and the additional air chamber is formed.When the air spring is in static deformation, that is, when the train is still or running at low speed, the pressure difference is small, and the throttle hole does not produce a large damping force.However, in high-speed train operation, the vibration of air spring is aggravated, the pressure difference between air spring and the additional air chamber is increased, and the throttle hole has an obvious damping effect, which absorbs vibration energy to attenuate vibration.
The air spring system of additional air chamber is composed of air spring body, throttle hole and additional air chamber.When the air spring is deformed by external load, the pressure difference between the air spring body and the additional air chamber is formed.When the air spring is in static deformation, that is, when the train is still or running at low speed, the pressure difference is small, and the throttle hole does not produce a large damping force.However, in high-speed train operation, the vibration of air spring is aggravated, the pressure difference between air spring and the additional air chamber is increased, and the throttle hole has an obvious damping effect, which absorbs vibration energy to attenuate vibration.
